Feidhmeanna bunúsacha an tsoláthair cumhachta rialaithe DC
Go ginearálta tá il-aschuir ag an soláthar cumhachta rialaithe DC: mar shampla, soláthraítear aschur seasta de 5V agus 2A; soláthraítear dhá aschur inchoigeartaithe (A agus B) le 0-24V agus 0-1A. Go ginearálta tá dhá mhodh oibre ag aschur inchoigeartaithe: rialachán voltais agus rialachán reatha. Déantar an dá mhodh oibre seo a thiontú go huathoibríoch le hathrú an ualaigh, agus taispeánann an stiúir ar phainéal tosaigh na hionstraime na modhanna CV agus CC. Go ginearálta, léiríonn an solas glas CV (Rialachán voltais), léiríonn an solas dearg CC (sruth seasta).
Some regulated power supplies also provide series A and B series work and master{{0}}slave tracking work at the same time. If path A is the master path and path B is the slave path, when tracking the working mode, the output voltage of the slave path changes with the master path, which is more suitable for occasions that require a symmetrical bipolar power supply. If the two circuits A and B work in series, they can output 048V, 01A DC power; in the series tracking mode, they can output 0±24V, 01A DC power.
